HVC supply high voltage diodes as alternative replacement of High Voltage Diode from HVCA (Dean Technology) 10kv, 20kv, 30kv, 40kv high voltage diode manufacturer.
Most of HVC Capacitor’s customer use high voltage ceramic capacitor and high voltage diode to build Voltage multiplier, (CASCADE COCKCROFT-WALTON VOLTAGE MULTIPLIER in high voltage generator) which is basic circuit for X-ray, CT and NDT machine.
In 2018, HVC Capacitor partner with local famous HV diode producer to win quite a lot HV projects. Customers also approval HVC brand Diode. In this market, most clients using HVCA diode from U.S.A, and more famous names like Japanese Origin and Sanken. All of above is not world-class renown brands like Vishay, TDK, Murata. Since this is specialized market and not massive product market like home electronics and consumer electronics. HVC HV diode widely used in aerospace, military weapons, mote vehicles, medical X-ray machine, electrostatic dedustings, scientific research institute.
Above mention HVCA diode have production base in Northeastern and Southeastern China. HVC brand high voltage diode with the same quality standard to Chinese producer and already gaining more and more replacement project in Europe and American market
HVC high voltage diode with the following advantage feature:
1) Low leakage current, high surge, and high current shock resistance
2) High reverse voltage, low forward current and avalanche breakdown protection.
3) Fast response, high efficiency and ultra-fast recover tiime.
4) High heat resistance, PN junction temperature up to 175℃
Following are detail HVD Diode Pn as alternative replacement equivalent for HVCA diodes.
Know more info check: https://www.hv-caps.com/High_Voltage_Diode/2019/1212/3343.html
|
Part Number |
Repetitive |
Average |
Maximum Reverse |
HVC Diode |
|
Reverse |
Output |
Recovery |
Alternative |
|
|
Voltage（VRRM） |
Current（IO） |
Time（Trr） |
Replacement |
|
|
|
|
|
Equivalent P/N |
|
|
HVCA Brand |
|
|
|
|
|
DV6P |
6KV |
75mA |
75ns |
HVD-SL6G75 |
|
DV8P |
8KV |
60mA |
75ns |
HVD-SL8G60 |
|
DV10P |
10KV |
55mA |
75ns |
HVD-SL10G55 |
|
G6FS |
6KV |
25mA |
100ns |
HVD-SL6G25 |
|
G7FS |
7KV |
25mA |
100ns |
HVD-SL7G25 |
|
G8FS |
8KV |
25mA |
100ns |
HVD-SL8G25 |
|
G10FS |
10KV |
25mA |
100ns |
HVD-SL10G25 |
|
G12FS |
12KV |
25mA |
100ns |
HVD-SL12G25 |
|
G15FS |
15KV |
25mA |
100ns |
HVD-SL15G25 |
|
G20FS |
20KV |
25mA |
100ns |
HVD-SL20G25 |
|
G25FS |
25KV |
25mA |
100ns |
HVD-SL25G25 |
|
G30FS |
30KV |
25mA |
100ns |
HVD-SL30G25 |
|
G2FSA |
2KV |
25mA |
75ns |
HVD-SL2G25 |
|
G3FSA |
3KV |
25mA |
75ns |
HVD-SL3G25 |
|
G4FSA |
4KV |
25mA |
75ns |
HVD-SL4G25 |
|
G5FSA |
5KV |
25mA |
75ns |
HVD-SL5G25 |
|
HL300 |
3KV |
40mA |
100ns |
HVD-SL3G40 |
|
HL500 |
5KV |
40mA |
100ns |
HVD-SL5G40 |
|
HL800 |
8KV |
40mA |
100ns |
HVD-SL8G40 |
|
HL1000 |
10KV |
40mA |
100ns |
HVD-SL10G40 |
|
HL1200 |
12KV |
40mA |
100ns |
HVD-SL12G40 |
|
HVEF8P |
8KV |
30mA |
20ns |
|
|
HVEF10P |
10KV |
20mA |
20ns |
|
|
HVEF12P |
12KV |
20mA |
20ns |
|
|
NV20FP |
2KV |
20mA |
80ns |
HVD-SL2G20 |
|
NV30FP |
3KV |
20mA |
80ns |
HVD-SL3G20 |
|
NV40FP |
4KV |
20mA |
80ns |
HVD-SL4G20 |
|
NV50FP |
5KV |
20mA |
80ns |
HVD-SL5G20 |
|
HVRT080 |
8KV |
30mA |
100ns |
HVD-SL8G30 |
|
HVRT120 |
12KV |
30mA |
100ns |
HVD-SL12G30 |
|
HVRT150 |
15KV |
30mA |
100ns |
HVD-SL15G30 |
|
HVRT200 |
20KV |
30mA |
100ns |
HVD-SL20G30 |
|
HVRT250 |
25KV |
30mA |
100ns |
HVD-SL25G30 |
|
HVRT300 |
30KV |
30mA |
100ns |
HVD-SL30G30 |
|
HVRL150 |
15KV |
30mA |
100ns |
HVD-SL15G30 |
|
HVRL200 |
20KV |
30mA |
100ns |
HVD-SL20G30 |
|
HVRL250 |
25KV |
30mA |
100ns |
HVD-SL25G30 |
|
HVRL300 |
30KV |
30mA |
100ns |
HVD-SL30G30 |
|
HVRL400 |
40KV |
30mA |
100ns |
HVD-SL40G30 |
|
HV07-12B |
12KV |
225mA |
/ |
HVD-SL312 |
|
HV37-08 |
8KV |
210mA |
150ns |
HVD-SL308G |
|
HV37-08F |
8KV |
210mA |
50ns |
HVD-SL208G |
|
HV37-10 |
10KV |
190mA |
150ns |
HVD-SL310G |
|
HV37-10F |
10KV |
190mA |
120ns |
HVD-SL310GF |
|
HV37-12 |
12KV |
250mA |
100ns |
HVD-SL312G |
|
HV37-12F |
12KV |
300mA |
80ns |
HVD-SL312GF |
|
HV37-20 |
20KV |
200mA |
100ns |
HVD-SL220G |
|
HV37-20F |
20KV |
200mA |
80ns |
HVD-SL220GF |
|
CL03-08 |
8KV |
400mA |
100ns |
HVD-SL03-08 |
|
CL03-10 |
10KV |
300mA |
100ns |
HVD-SL03-10 |
|
CL03-12 |
12KV |
250mA |
100ns |
HVD-SL03-12 |
|
CL03-15 |
15KV |
200mA |
100ns |
HVD-SL03-15 |
|
CL03-20 |
20KV |
120mA |
100ns |
HVD-SL03-20 |
|
CL03-30 |
30KV |
120mA |
100ns |
HVD-SL03-30 |
|
2CL2FF |
8KV |
60mA |
150ns |
HVD-2CL2FF |
|
2CL2F |
8KV |
100mA |
/ |
HVD-2CL2F |
|
2CL2FG |
10KV |
60mA |
150ns |
HVD-2CL2FG |
|
2CL2G |
10KV |
100mA |
/ |
HVD-2CL2G |
|
2CL2FK |
10KV |
140mA |
100ns |
HVD-2CL2FK |
|
2CL2FH |
12KV |
60mA |
150ns |
HVD-2CL2FH |
|
2CL2H |
12KV |
100mA |
/ |
HVD-2CL2H |
|
2CL2FJ |
15KV |
60mA |
150ns |
HVD-2CL2FJ |
|
2CL2J |
15KV |
100mA |
/ |
HVD-2CL2J |
|
2CL2FL |
15KV |
120mA |
100ns |
HVD-2CL2FL |
|
2CL2FM |
20KV |
100mA |
/ |
HVD-2CL2FM |
|
2CL2FP |
30KV |
140mA |
100ns |
HVD-2CL2FP |
|
2CL2FR |
35KV |
100mA |
100ns |
HVD-2CL2FR |
|
2CL105 |
9KV |
450mA |
/ |
HVD-2CL105 |
|
2CL106 |
12KV |
450mA |
/ |
HVD-2CL106 |
|
UX-FBR8 |
8KV |
420mA |
/ |
HVD-2CL8KV/420mA |
|
UX-FOB |
8KV |
500mA |
/ |
HVD-SL513G |
|
UX-F2CL15 |
15KV |
150mA |
50ns |
HVD-2CLG15KV/150mA |
|
UX-F15B |
15KV |
200mA |
50ns |
HVD-2CLG15KV/200mA |
|
UX-F30B |
30KV |
100mA |
50ns |
HVD-2CLG30KV/100mA |
|
2CL105 |
9KV |
450mA |
/ |
HVD-2CL105 |
|
2CL106 |
12KV |
450mA |
/ |
HVD-2CL106 |
|
BR2F |
2KV |
900mA |
100ns |
HVD-SL2F |
|
BR2 |
2KV |
1000mA |
/ |
HVD-SL2 |
|
BR3F |
3KV |
900mA |
100ns |
HVD-SL3F |
|
BR4F |
4KV |
600mA |
100ns |
HVD-SL4F |
|
BR4 |
4KV |
850mA |
/ |
HVD-SL4 |
|
BR5F |
5KV |
600mA |
100ns |
HVD-SL5F |
|
BR6F |
6KV |
500mA |
100ns |
HVD-SL6F |
|
BR8F |
8KV |
400mA |
100ns |
HVD-SL8F |
|
BR10F |
10KV |
250mA |
100ns |
HVD-SL10F |
|
BRU10SF |
10KV |
250mA |
75ns |
HVD-SLU10SF |
|
HV200UF3 |
3KV |
375mA |
50ns |
HVD-SL200UF3 |
|
HV200UF4 |
4KV |
375mA |
50ns |
HVD-SL200UF4 |
|
HV200UF5 |
5KV |
375mA |
50ns |
HVD-SL200UF5 |
|
HV550S08 |
8KV |
550mA |
/ |
HVD-HV600S08 |
|
HV550S10 |
10KV |
450mA |
/ |
HVD-HV600S10 |
|
HV550S12 |
12KV |
400mA |
/ |
HVD-HV600S12 |
|
HV550S15 |
15KV |
350mA |
/ |
HVD-HV600S15 |
|
HV550S20 |
20KV |
250mA |
/ |
HVD-HV600S20 |
|
HV550S25 |
25KV |
200mA |
/ |
HVD-HV600S25 |
|
HV550S30 |
30KV |
200mA |
/ |
HVD-HV600S30 |
|
HV550S45 |
45KV |
100mA |
/ |
HVD-HV600S45 |
|
HVCF25 |
2.5KV |
1500mA |
75ns |
HVD-2CLG2.5KV/1.5A |
|
HVCF50 |
5KV |
1200mA |
75ns |
HVD-2CLG5KV/1.2A |
|
HVCF100 |
10KV |
650mA |
75ns |
HVD-2CLG10KV/0.65A |
|
HVRW1 |
1KV |
2500mA |
150ns |
HVD-HVRW1 |
|
HVRW2 |
2KV |
1500mA |
150ns |
HVD-HVRW2 |
|
HVRW3 |
3KV |
1500mA |
150ns |
HVD-HVRW3 |
|
HVRW4 |
4KV |
1000mA |
150ns |
HVD-HVRW4 |
|
HVW3 |
3KV |
2000mA |
/ |
HVD-HVRM3 |
|
UFHV2K |
2KV |
550mA |
75ns |
HVD-SL2G550 |
|
UFHV3K |
3KV |
400mA |
75ns |
HVD-SL3G400 |
|
UFHV4K |
4KV |
350mA |
75ns |
HVD-SL4G350 |
